Stihl TSA230.1 Cordless Cut-off Saw - AP System (unit only)
TSA 230.1 Cordless Cut-Off Machine tool only: Battery-powered with 9" cutting wheel
Please note that this model is only available as a tool only without battery and charger. If you do not already have a battery or charger, please make sure that you add these to your basket.
The TSA 230.1 is a 9” (230 mm) battery-powered cut-off machine in the STIHL AP System. It’s exceptionally easy to handle thanks to its compact and well-balanced design and is designed for professionals working in construction, hardscaping and pipework – making it an ideal choice for making short cuts on paving stones, brickwork and steel.
The TSA 230.1 has improved cutting performance compared to the TSA 230.0 model, with a higher power output of 2.1 kW and faster overall cutting speed. This extends the types of jobs and applications the cut-of machine can carry out. The cut-off machine comes as standard with a powerful 9” / 230 mm composite resin cutting wheel which has a very high cutting performance, however we recommend fitting the TSA 230.1 with a D-SB80 diamond cutting wheel for longer and more intensive jobs.
As the TSA 230.1 is battery-powered, it has low noise emissions during cutting. It is fitted with a powerful low-maintenance EC motor which operates almost wear-free, is quiet and has smooth running and low vibrations – it also ensures the tool operates at optimum performance throughout the entire battery charge.
Thanks to its emission-free operation, the TSA 230.1 can be used inside buildings. The integrated water connection is easy to set-up too. A fixed magnesium guard has an integrated water guide and is reinforced by stainless steel, providing a clear view of the cutting wheel during use. An integrated spindle lock makes for quick and easy changing of the cutting wheel – simply press the spindle lock, loosen the retaining screw and then tighten it again.
The TSA 230.1 must be used with the AP 300 S battery for maximum performance. If you use an AP 200 S, there will be a reduction in performance. On a full charge with the AP 300 S, the TSA 230.1 has a working time of 20 minutes.
Technical Data
| Rated voltage | 36 V |
| Max. voltage | 40 V |
| Power | 1.60 kW 1) |
| Battery system | AP |
| Recommended battery | AP 300 S |
| Device weight without battery | 3.9 kg 2) |
| Cutting disc diameter | 230 mm |
| Max. cutting depth | 70 mm |
| Min. battery working time AP 200 S | 9 min 3) |
| Max. battery working time AP 200 S | 14 min 3) |
| Min. battery working time AP 300 S | 15 min 3) |
| Max. battery working time AP 300 S | 24 min 3) |
| Max. battery working time AP 500 S | 26 min 3) |
| Device length with cutting disc | 55 cm |
| Sound pressure level | 104 dB(A) 4) |
| Sound power level | 115 dB(A) 5) |
| Vibration level left | 4.3 m/s² |
| Vibration level right | 2.4 m/s² |
